Wall Dividers & Screens

Smart customisable wall divider and screen system

enquirerequest samples
Fire Rating Solid Timber
Group 1S New Zealand
Group 1 Australia
Fire Rating MDF/Veneer
Group 1S New Zealand
Group 2 Australia
Key FeaturesFitting SystemsType of Battenproduct detailsinstallationprojects

Key Features

  • 10 year product warranty solid timber | 5 year product warranty MDF / timber veneer
  • Group 1S fire rated - New Zealand
  • Group 2 fire rated - Australia
  • Ask about our FSC® / PEFC™ certified products - contributes to Greenstar and Homestar credits
  • Customisable batten spacings and batten sizes
  • Standard sizes: 30x45mm, 30x90mm, 30x140mm
  • 43x43mm, 43x90mm (standard size), 43x140mm
  • Three options for top and bottom fixings
  • Typical batten spacing is 70mm to 100mm centers

Fitting systems

System 1

​​​Individual installation

Bracket & bolt fixing

Batten spacing at your specification

Individual c-bracket batten support

Each batten (batten, brackets and bolts) will need to be installed individually.

System 2

Base u-channel and top u-channel fixing

Screw fix fixing

Batten spacing at your specification

Top and bottom u-channel fixing and mid height continuous support rod

Aluminum top and bottom u-channels are fabricated then black powder-coated. Battens are placed in channels then screw fixed at the desired spacings​All dividers are fabricated to the height required.

System 3

Base plate and top plate fixing

Group installation

Guaranteed linear spacings

Top and bottom plate fixing and mid height continuous support rod

Aluminum top and bottom plates are fabricated then black powder-coated. Rebates are machined into the battens to accommodate the 90mmx12mm fins.​All dividers are fabricated to the height required.

Type of Batten

Solid Timber

The colours shown are as accurate as possible, but we recommend that you request product samples before making a final selection. ​

All timber species have their own natural variations of colour and grain and product samples may not fully reflect the colour variation that can occur.

Some species are FSC® or PEFC™ certified so please ask for more information.​Other species may also be available on request.

Solid timber with intumescent coating​Group 1S fire rating (NZ)

New zealand Native timbers

Australian Native timbers

Exoctic Timbers

Certified timbers

FR MDF/ Timber Veneer

Real timber veneer bonded onto MDF core makes for a strong and sturdy batten. Timber veneer is available in the colour choices shown.

Some MDF and timber veneer species are FSC® or PEFC™ certified - please ask for more information.

FR MDF/Timber Veneer:
​Group 2 fire rating (AU)
​Group 1S fire rating (NZ)

Timber Veneer Species

Product Details

Finishing

All battens are finished in the factory. Zenthe clear flat varnish is our standard finish

Some white wash & stains are available if matching to other finishers is required. Please contact us today.

Timber Species
Bolting

Fix U-bracket to substrate:
CONCRETE - Stainless steel M8x40 masonry anchor with countersunk barrel nut​
Fasten batten in U-shaped bracket:
M6 joint connector bolt and M6 barrel nut

Screwing

Fix U-bracket to substrate:
WOOD SUBSTRATE - Countersunk wood screws​.

Acoustic & Sound Insulation

Acoustic panels can be incorporated into the divider system to make a screen, recommended at 25mm thick for greater acoustic performance. Rebates formed in the battens house the panels snug.The acoustic panels have a group 1 (Aus.) and group 1S (NZ) fire rating. Available in black.NRC rating up to 0.60 (depending on batten spacings)

installation

Application

Zenthe Batten Wall Divider

Connector Rod Detail View
Application

Zenthe Batten Wall Divider

Bottom plate Detail View with U-Bracket
Application

Zenthe Batten Wall Divider

Connector Rod Detail View
Application

Zenthe Free Standing Screen

Bottom Plate Detail View with U-Bracket
Application

Zenthe Free Standing Screen

Connector Rod Detail View
Application

Zenthe Free Standing Screen

Bottom Plate Detail View
Application

Zenthe Free Standing Screen

Acoustic
Application

Zenthe Free Standing Screen

Bottom Plate Detail View - Acoustic

Projects USING this product

TECHNICAL DOWNLOADS

Access Architect downloads

View our extensive online library of technical information, full CAD/BIM Revit Families, detailed component files, testing & Environmental information and  much more.

view downloads
